Force Sensing Resistor RP-S4.6-L12-LF10 FSR sensor

Force Sensing Resistor RP-S4.6-L12-LF10 resistive varistor is a flexible thin film sensor whose resistance value decreases as the pressure on the acting sensing zone increases.

$1.26(Sample price)

1

Piece/Pieces

The FSR sensors
use high-tech raw materials

Force Sensing Resistor RP-S4.6-L12-LF10 is made of excellent mechanical properties
Polyester film, composed of highly conductive materials and nano-scale pressure-sensitive materials,
The top layer is a flexible film and a pressure-sensitive layer compounded on top, and the bottom layer is soft
film and composite on the top of the conductive circuit. Both through double-sided tape
Bonding and isolation of the sensing area. When the sensing zone is pressurized, it is on the bottom layer
Lines that are disconnected from each other are channeled through the top-level pressure-sensitive layer of the port
The output value of the resistor varies with the pressure.

Features of thin film sensors

  • Excellent strength sensing
  • Fast response time
  • Long durability life
  • Long service life
  • Simple circuit principle, easy to apply
  • Customizable

Product Parameter

Thickness: 0.25mm
Shape: Flexible
Starting Force: 10g
Force Range: 10g~500g
10g Force Output: Resistance <200KΩ
500g Force Output: Resistance 3~5KΩ
Reaction Mode: Contact compression
None-actuated Resistance: > 20M Ω
Activation Time: < 0.01S
Operating Temperature: -20℃~+65℃
Durability: > 1 million times(Normal writing press)
Resistance Working Range: 2K~100KΩ
Response Time: < 1ms
Waterproof: No
Dustproof: No
EMI: Generates no EMI
EDS: Not ESD sensitive
